Commercial XL Drum Anchor Winch

Name: Commercial XL Drum Anchor Winch
Brand: Savwinch
SKU: 9005
Price: 6355.71 AUD
Availability: InStock

Patented design

$6,355.71 AUD

Sale

inc. GST

Rated 4.9 on Google

Suits Boats Up To9-14m

Motor, Gearbox, Drum316 Stainless Steel

WaterproofIP68

Fast FallTrue

In stock

SKU: 9005

Add To Your Install (Optional) Wireless Remote Control +$170.00

Ticked add-ons go in with Add to cart. Express checkout is hidden while an add-on is ticked.

Dispatched within 3 to 5 business days. Need it sooner? Call us on +61 3 8361 8841. Shipping and returns

Not sure which winch fits your boat? Find out with SavMatch™

A True Free Fall Drum Winch For Large Vessels

Drop fast. Hold hard. Built for commercial use.

Our international award winning Drum Winches feature specifically designed marine grade patented motors and oversized Worm Drive Gearboxes and are IP68 rated to suit even the harshest environments. The motors can be moved into 12 different positions to ensure that each Drum Winch can be installed on almost any vessel.

The Commercial Range is our only range of Drum Winches to feature a true free fall system. While our smaller Winches can utilise our EFF™ Electronic Fast Fall System, the Commercial XL can freely drop the anchor, getting you to your mark as fast as the anchor can drop.

Includes an Up/Down Switch, Solenoid, Circuit Breaker, Guide Roller and Free Fall Accessories. Custom rope kits are available on request. Suitable for boats up to 30m (98ft).

Patented technology

Engineered To Survive The Water It Works In E n g i n e e r e d T o S u r v i v e T h e W a t e r I t W o r k s I n

Two things inside this winch that you will not find on a spec sheet comparison.

Savwinch drum winch motor housing shown disassembled with internal components

Patented injection mould P a t e n t e d i n j e c t i o n m o u l d

Sealing the motor was not enough. A patented injection mould fills every air pocket inside the motor, so there is nowhere for condensation to form.

Condensation is one of the main causes of motor failure in the marine industry. Once water takes hold, rust and corrosion follow. The casing is a solid block with no covers or sleeves.

Emergency manual release E m e r g e n c y m a n u a l r e l e a s e

Drop your anchor without power. An allen key disengages the drum so it spins freely, and a hand crank can be fitted to wind the winch back in if your battery fails.
